Database For Vintage and Classic Smiths Vehicle Jacks
Other vintage British car jack databases:
George Radion in Australia has a database on Australian-made Jacks
Page 1 for Folding A Frame; Fixed A Frame
Tubular Side Lift followed by Scissor; Screw; Lever Action; Hydraulic; Integrated; and Trolley
|
Tubular (Pole) Side Lift Jacks
|
|
|
|
Stevenson Side Lift - Attached Handle Description This Stevenson pole jack has a substantial flip over handle. The dimensions - 18 inches when fully wound down, lifting arm protrudes 4.5 inches which would fit a 3/4" square hole, as I doubt there would be a matching Z shaped orifice! The base is cast STEVENSON JACKING SYSTEM WORLD PATENTS. The lifting arm is cast SK65833. Photos and data courtesy of George Radion in Australia. Applicable Vehicles: Not known Jack Handle Type: Integrated Year Dates Noted:
Value:
|
|
|
Smiths Stevenson - Z Lifting Arm Description This Smiths Stevenson pole jack has the same style 'Z' lifting arm as the one above but is operated by a ratchet. The dimensions - 18" when fully wound down, lifting arm protrudes 4.5". The base is cast SMITHS STEVENSON JACKING SYSTEM. The lifting arm is cast SK85078. Applicable Vehicles: Not known Jack Handle Type: Ratchet as shown. Stamped on one side TO LIFT SJS and TO LOWER on the other. Year Dates Noted: Circa 1937. Value: Average price paid in 2021 = £21.00 - 1 sale
|
|
|
Description This Smiths Stevenson pole jack has an integrated handle and a unique lifting arm. In the second photo it can be seen in position inside the car. A blanking cover has been removed from the floorboards and the jack arm inserted in a chassis cross member. The lifting arm can be raised from 4.25" to 15.75". The lifting peg is 5/8" diameter. Photo and details are courtesy of Paul Ainsworth who has owned his Morgan +4 for 50 years. Applicable Vehicles: Morgan +4 Jack Handle Type: Integrated Year Dates Noted: 1950s Value:
|
|
|
Description This Smiths Stevenson pole jack is very similar to many others except for the lifting arm which has been made to fit a trailer frame. Applicable Vehicles: Trailer Jack Handle Type: Hexagonal ratchet or wheel brace. Year Dates Noted:
Value: Average price paid in 2021 = £15.00 - 1 sale
|
|
|
Description This version with the cylindrical lifting arm is for the Rover P2. 20 inches tall extended. Arm is 2.5 inches. Applicable Vehicles: Rover P2. Jack Handle Type: Wheel nut Brace (handle marked PENANT) as shown in photos. Year Dates Noted:
Value: Average price paid in 2016 = £51.43 - 1 sale Average price paid in 2017 = £75.00 - 1 sale Average price paid in 2019 = £27.00 - 1 sale
|
|
|
Smith Stevenson Daimler Conquest & Century Description As shown in the photos. Pole jack with a clamped side arm of considerable length and a rivetted stop half way along its length. Applicable Vehicles: Daimler Conquest Saloon 1953 to 1956. Daimler Conquest Century Saloon 1954 to 1958 Jack Handle Type: Wheel nut brace. Year Dates Noted: Circa 1953 to 1958. Value: Average price paid in 2016 = £35.00 - 2 sales Average price paid in 2017 = £14.00 - 1 sale Average price paid in 2019 = £10.25 - 1 sale
|
|
|
Description The jack is operated using the wheel brace by rotating the hex end at the top. The square section (painted black) engages into the jacking point's square tube on the vehicle chassis (located just under the outer sills) and is actually a heavy "H" section steel forging. Photo and information courtesy of Andrew Henshall in Australia. Similar, if not identical to the Jaguar version in next entry. Applicable Vehicles: Jowett Javelin 1947 to 1953 Jack Handle Type: Wheel brace. Year Dates Noted: Known to be in use 1947 to 1953 Value: Average price paid in 2013 = £20.00 - 1 sale Average price paid in 2014 = £87.97 - 2 sales Average price paid in 2015 = £64.96 - 3 sales
|
|
|
Stevenson (Smiths) Jaguar XK120/140/150 Stevenson (Smiths) Jaguar Mk IV & Jaguar Mk V Description The diagram shows the Jaguar XK120 toolkit with a Stevenson sidelift jack incorporating a welded square section lifting arm. It is courtesy of SC Parts. However, a long time owner (Rob Reilly) has sent me numerous photos and the following description that indicates the lifting arm for the XK120 was originally bolted in a fixed position and was of an H section. It was later changed to the square welded arm shown in the diagram. Rob Reilly describes the history of the Jaguar XK Series; Jaguar Mk IV; and Jaguar Mk V which shared the same jack: "Here are a few pictures of one of the Stevenson jacks for my own 1950 Jaguar Mark V and 1951 XK120. Both cars were equipped with the same jack. I also include pictures of a ratchet handle and a brace with socket. The short history of this design is thus: 1945-48 Jaguar Mark IV used this design with a 3/4” hex drive (possibly slightly smaller - may have been 7/16" Whitworth) and a 7” long solid square bar side arm. It was operated by an s-bend cranking handle with a socket on the end. 1948-49 Jaguar Mark V 4 door saloon initially used this same basic design with the 3/4” hex drive and a 5-1/4” long side arm of H cross section. The foot is labelled STEVENSON JACKING SYSTEMS WORLD PATENTS. There is a hole in the floor of the car for access where the jack fits into a socket on the chassis frame. It was operated by a brace with a 3/4” socket on the end also used for the wheel nuts. Then in 1949 it was discovered that the wheel nut brace was cumbersome to operate in the confines of the Mark V 2 door Drop Head Coupe and the XK120. Because of this, the jack was changed to a 1/2” hexagon drive and now operated by a ratchet handle. This change was applied in mid 1949 to all 3 Jaguar models then in production; Mark V saloon, Mark V Drop Head Coupe and XK120. Later (unknown date) the wording on the foot was changed to SMITHS STEVENSON JACKING SYSTEMS. Another change (unknown date), probably a cost reduction, was to eliminate the H section clamped side arm and substitute a square tube welded onto the side of the round main body. Another change (unknown date), also probably a cost reduction, was to eliminate the forged foot and substitute a pressed steel foot. This basic design continued on 1949-51 Mark V, 1948-54 XK120, 1954-57 XK140, and 1957-61 XK150, but with most XK150s it was painted black and had a decal with the name PRIMA." One jack with the welded arm was recently advertised on Ebay March 2017). It had 4/53 punched under the foot. Applicable Vehicles: Jaguar Mark IV. Jaguar Mark V Jaguar XK120 Jaguar XK140 Jaguar XK150 (changed to Prima jack at some point). Jack Handle Type: Wheel brace originally. Ratchet. Year Dates Noted: 1953 Value: Average price paid in 2017 = £262.78 - 1 sale Average price paid in 2018 = £337.05 - 2 sales Average price paid in 2019 = £208.99 - 1 sale Average price paid in 2020 = £21.00 - 1 sale Average price paid in 2021 = £93.67 - 2 sales - Welded arm Average price paid in 2021 = £81.00 - 1 sale - Pivot arm Average price paid in 2022 = £198.00 - 1 sale - Welded arm Average price paid in 2023 = £36.67 - 1 sale - Welded arm
|
|
|
Description This jack is similar to the one above. However, as I have dedicated that entry to the Jaguar I have made this separate entry. The jack is shown in position on a 1937 Standard Flying 9. The lifting bar is an H section. My photo. Applicable Vehicles: Standard Flying 9 Jack Handle Type: Wheel Brace.. Year Dates Noted: 1937 Value:
|
|
|
Description This jack is similar to a number of Smiths/Stephenson tubular side lift jacks. However, I have given it a separate entry until I can establish finer detail. What is known is that it is a Stephenson jack and it has a hexagon winding nut to accommodate the wheel nut brace. It also appears to have a bracketed lifting arm but I cannot determine the cross section of the arm, nor its length. Photo and details courtesy of NewMoody. Applicable Vehicles: Vauxhall 14 Velox Jack Handle Type: Wheel Brace. Year Dates Noted: 1934 to 1953 Value:
|
|
|
Smith Stevenson Side Lift - H Spigot Description This jack is similar to the one above except that it has the later 0.5" square drive with the earlier H cross section hinged lifting arm. It is 14.5 " high. It also has what is probably a storage bracket bolted to the side of the lifting arm. Applicable Vehicles: One vendor claimed it was for a Morgan 3-Wheeler. Information required please. Jack Handle Type: Ratchet as shown in 5th photo. Year Dates Noted:
Value: Average price paid in 2015 = £68.66 - 1 sale Average price paid in 2016 = £131.89 - 1 sale
|
|
|
Smith Stevenson Side Lift - Π Arm Description This post jack has an invert U lifting arm and a hexagonal winder. No other details known. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted:
Value: Average price paid in 2015 = £28.77 - 1 sale
|
|
|
Smith Stevenson Side Lift - Cranked Arm Description Similar to other post jacks but with a cranked lifting arm. Stamping on the would suggest a Morris car. 18" high; 1/2" drive. The final 2 pictures show the jack with the cranked arm the other way round and with stamping stating SLS PATENT xxxxx MOR 1900. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted:
Value: Average price paid in 2016 = £24.50 - 1 sale Average price paid in 2017 = £155.00 - 1 sale
|
|
|
Smiths Stevenson - Square Shoulder Extension Description Similar to other post jacks but with a square shouldered extension. I do not know if this was an owner modification. Any information welcome. Applicable Vehicles: Not known Jack Handle Type: Wheel brace Year Dates Noted:
Value: Average price paid in 2019 = £75.00 - 1 sale
|
|
|
Description The Standard 14 Drop Head Coupe handbook shows the attached jack that I assume is a Smiths jack as Smiths supplied other Standard cars. The jack looks very similar (possibly the same) to the one shown immediately above. I would welcome clarification and photos from Standard 14 owners. Applicable Vehicles: Standard 14 and Standard DHC. Jack Handle Type: As shown in the photo. Year Dates Noted:
Value: Average price paid in 2015 = £14.99 - 1 sale Average price paid in 2016 = £15.05 - 1 sale Average price paid in 2017 = £58.89 - 1 sale Average price paid in 2018 = £94.00 - 1 sale Average price paid in 2022 = £20.00 - 1 sale Average price paid in 2023 = £26.00 - 1 sale
|
|
|
Description Cast with SMITH STEVENSON JACKING SYSTEMS on the circular foot. 16.5" high retracted and 27" when extended. The arm is 2.25" long. See here for Pre War jack. Final photo is from the Austin 8 part list dated 1946. Noticed as original equipment in a Wolseley 8. held in a bracket in the engine compartment on the bulkhead. Applicable Vehicles: Austin 8 1946 to 1948 Wolseley 8 Jack Handle Type: Wheel brace. Year Dates Noted:
Value: Average price paid in 2020 = £16.00 - 1 sale
|
|
|
Description This side lift jack has a fixed lifting arm of a very short length. It raises fro 15" to 26". It was apparently from a circa 1945 Austin car. The arm is 25mm diameter and 6cm long. Applicable Vehicles: Austin Devon Jack Handle Type: not known. Year Dates Noted: 11/50 Value: Average price paid in 2015 = £45.81 - 3 sales Average price paid in 2017 = £42.49 - 2 sales Average price paid in 2018 = £77.00 - 1 sale Average price paid in 2019 = £18.77 - 1 sale
|
     |
Smiths Stevenson Pole - Reinforced Arm Description Unusual reinforced arm Smiths Stevenson pole jack. Approx 18" closed with a reinforced round arm 8.5" long. Apart from the SMITHS STEVENSON JACKING SYSTEMS casting on the foot, the owner found a faint stamping SMITHS STEVENSON JACKING SYSTEMS HD #5 at about 2" down from the top of the tube. The underside of the base is also stamped BTW/62. Applicable Vehicles: Not known Jack Handle Type: Possibly wheel brace or ratchet spanner. Year Dates Noted: Possibly 1962.
Value: |
|
|
Description This side lift jack Is cast on the circular base STEVENSON JACKING SYSTEMS WORLD PATENTS. Height is 425mm (16.7"), jacking shoe is 195 x 50 mm (7.6 x 1.96") and the circular base 70mm (2.75"). Applicable Vehicles: Daimler 15 1936 & 1937 - Chassis numbers 40450 - 46099. Lanchester 11 1937/1938 Jack Handle Type: Wheel brace as shown in the final photo. Year Dates Noted: 1936 - 1937 Value: Average price paid in 2021 = £10.00 - 1 sale
|
|
|
Description This bumper jack is stamped SMITHS JACKING SYSTEMS No.528933 SPEEDY JACK. It is 26 inches high extended and 18 inches lowered. The effective lifting point of the hook goes from 8 inches to 16 inches. It was used by the Ford Prefect E93A and the Ford Popular E93A. In those vehicles the jack goes through (deliberate) holes in the wooden floor and hooks into recesses on the inside of the chassis rails. It can even be done from inside the car when it's raining using the wheel brace to wind it - but you then have to go outside and get wet to change the wheel! Applicable Vehicles: Ford Prefect (E93A) 1938 to 1949. Ford Popular (E93A) 1953 to 1959. Jack Handle Type: Wheel brace. Year Dates Noted:
Value: Average price paid in 2017 = £35.66 - 3 sales Average price paid in 2018 = £18.19 - 5 sales Average price paid in 2019 = £0.99 - 1 sale
|
|
|
Smiths - Fixed Arm Description The base is stamped SMITHS STEVENSON SYSTEMS PAT No. 528933. The driver nut is 6/6"W. The jack extends from 17.75" to 30". In its lowered position the lifting arm is 7" from the ground. Applicable Vehicles: Not known Jack Handle Type: Not known. Year Dates Noted:
Value: Average price paid in 2015 = £8.09 - 2 sales Average price paid in 2016 = £119.75 - 1 sale Average price paid in 2017 = £12.29 - 2 sales Average price paid in 2020 = £10.50 - 1 sale
|
|
|
Description This jack varies from the one immediately above having a shorter lifting arm. Height unextended = 17.5" Height extended - 30.75" Diameter, main shaft = 13/16" Diameter base plate = 2.5" Nut = 7/16" Whitworth Lifting arm is 7/8" square tube. Arm top length = 4.25" Arm bottom length = 4-7/8"Applicable Vehicles: Not known. Information required please. Jack Handle Type: Wheel nut brace. The brace shown is believed to be original. Year Dates Noted:
Value: Average price paid in 2017 = £20.66 - 3 sales |
|
|
Smiths Reinforced Tubular Sidelift Description This jack varies from the two above having a reinforcing gusset to the lifting arm. The base is cast SMITHS STEVENSON SYSTEMS. Height unextended = 17.5" Height extended = 30." Diameter, main shaft = 13/16" Diameter base plate = 2.5" Nut = 7/16" Whitworth Lifting arm is 7/8" square tube. Arm length = 4.9" Photos and data courtesy of Gary Skinner. Applicable Vehicles: Hillman Minx Mk 4 saloon. Jack Handle Type: Wheel nut brace. Year Dates Noted: 1949 to 1951 Value:
|
|
|
Smiths Stevenson Exposed Post Screw Description This side lift jack is an exposed screw side lift jack. The base is cast STEVENSON JACKING SYSTEM WORLD PATENT. It has a square winder. No other details known. Applicable Vehicles: Not known. Jack Handle Type: Not known Year Dates Noted:
Value: Average price paid in 2018 = £6.00 - 1 sale
|
|
|
Description This bumper jack is for the very early Triumph TR2. The 3rd and 4th photos are from the 1st Edition Triumph TR2 Driver's Handbook. The later TR2, TR3, TR3A, TR3B used the Smiths jack immediately below. Any further information from Triumph experts most welcome. Applicable Vehicles: Triumph TR2 (early). Jack Handle Type: As shown in the photo. Year Dates Noted:
Value: Average price paid in 2017 = £26.00 - 1 sale Average price paid in 2021 = £40.00 - 1 sale
|
|
|
Description Later Triumph TR2, TR3, TR3A and TR3B used this Smiths bumper jack with the enclosed winder thread. Part number is quoted as 110774. Final 2 pictures taken from the Triumph TR3 Driver's Handbook. Any further information from Triumph experts most welcome. Applicable Vehicles: Triumph TR2 (later), TR3, TR3A, TR3B and TR4. Swallow Dorretti. Jack Handle Type: As shown in photos. Year Dates Noted:
Value: Average price paid in 2014 = £40.69 - 1 sale Average price paid in 2015 = £44.66 - 3 sales Average price paid in 2016 = £26.75 - 2 sales Average price paid in 2019 = £57.60 - 1 sale Average price paid in 2020 = £155.00 - 1 sale Average price paid in 2023 = £50.00 - 1 sale
|
|
|
Description Only details as shown in the photo. Reported by the vendor to be for the Standard 8 and 10. The wheel nut brace in the first photo may not be the original (see second photo). Applicable Vehicles: Standard 8 and 10 Jack Handle Type: Wheel nut brace as shown in second photo. Year Dates Noted: 1950s Value: Average price paid in 2014 = £31.55 - 1 sale Average price paid in 2021 = £36.00 - 1 sale
|
 |
Description This picture is from the Austin 8 parts list 1939. It looks very similar to the Ezeyjack below other than the screw thread cut on only half the length. It may be artistic license by the graphics department. More information required. See here for Post War jack. Applicable Vehicles: Austin 8 1939, possibly also during war production. Jack Handle Type: Ratchet as shown. Year Dates Noted: 1939
Value: |
|
|
Description The Ezeyjack is the original open screw type of jack for bumper applications. Applicable Vehicles: A very similar jack (may be the same) was supplied with the Morris Minor Lowlight and Series 2 cars. Jack Handle Type: As shown in first photo, or wheel brace as shown in second photo. Year Dates Noted:
Value:
|
|
|
|
|
|
Description Only details as shown in the photo. Applicable Vehicles: Triumph TR7 Triumph TR8 Jack Handle Type: As shown in the photo. Year Dates Noted:
Value: Average price paid in 2014 = £20.00 - 1 sale Average price paid in 2021 = £47.99 - 1 sale
|
|
|
|
|
|
Description Very early example of a Stevenson (later Smiths) jack, standing 16 inches high. Cast STEVENSON JACKING SYSTEMS. Only details as shown in the photo. Photos courtesy of Stephen Eidmans. Applicable Vehicles: Not known Jack Handle Type: As shown in the photos. Year Dates Noted:
Value:
|
|
|
Smiths Commercial Description The jack is a single screw. Cast on one side MORRIS COMMERCIAL TYPE R and on the other S SMITHS & SONS (MA) LTD LONDON. Applicable Vehicles: Not known Jack Handle Type: As shown in third photo. Year Dates Noted:
Value: Average price paid in 2014 = £27.00 - 1 sale Average price paid in 2015 = £9.99 - 1 sale Average price paid in 2016 = £10.00 - 1 sale Average price paid in 2018 = £9.99 - 1 sale
|
|
|
Description: The Maxfield is a double screw jack. Cast MAXFIELD / 7 HI-LIFT / S SMITHS & SONS M A LTD LONDON / PATENTS 22817 204936. Photos courtesy of Dion Rinaldi in Australia. Applicable Vehicles: Not known. Jack Handle Type: Not known. Year Dates Noted:
Value: Average price paid in 2015 = £10.00 - 1 sale Average price paid in 2020 = £11.50 - 1 sale
|
|
|
Smiths Maxfield Adapto Description: The Maxfield Adapto is a single screw jack plus a very uncommon pegged main body adjustment. Cast MAXFIELD on one side, ADAPTO on the other and SMITHS OF LONDON somewhere else. Applicable Vehicles: Not known. Jack Handle Type: As shown in the fifth photo. Year Dates Noted:
Value: Average price paid in 2015 = £6.50 - 1 sale
|
|
Smiths Minor
|
|
|
|
Description Single screw jack. It is 6 1/4" closed and 9 1/2" extended. The base measures 4 3/4" x 3 1/4". Cast MINOR 6 on one side and SMITHS JACK on the other. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted:
Value: Average price paid in 2020 = £10.99 - 1 sale
|
|
|
Smiths Minor 7 Description Single screw jack. Cast MINOR 7 on one side and SMITHS SCREW JACK on the other. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted:
Value: Average price paid in 2014 = £5.00 - 1 sale Average price paid in 2015 = £4.99 - 2 sales Average price paid in 2017 = £10.00 - 1 sale Average price paid in 2018 = £24.50 - 2 sales
|
|
|
Description Single screw jack. Cast MINOR 8 on one side and SMITHS SCREW JACK on the other. Applicable Vehicles: Not known Jack Handle Type: As shown in 2nd photo. Year Dates Noted:
Value: Average price paid in 2013 = £8.59 - 1 sale Average price paid in 2014 = £9.99 - 1 sale Average price paid in 2015 = £20.72 - 2 sales Average price paid in 2016 = £5.50 - 1 sale Average price paid in 2018 = £12.00 - 1 sale Average price paid in 2020 = £13.50 - 2 sales Average price paid in 2022 = £20.00 - 1 sale Average price paid in 2023 = £11.61 - 1 sale
|
|
|
Description The Minor 9 is a single screw jack. Cast MINOR 9 on one side and SMITHS SCREW JACK on the other. It measures 9.5" closed and 15.5" extended. The base measures 5.5" x 3.5". The 3rd photo shows an identical cast jack for the Ern Lake Major 9 with only the winder mechanism castings and screw shaft varying in thread thickness and pitch. All photos and data courtesy of NewMoody. Applicable Vehicles: Not known Jack Handle Type: Likely to be similar to the minor 8 above. Year Dates Noted:
Value:
|
|
Smiths Major
|
|
|
|
Smiths Major 8 Description The jack is cast MAJOR 8 on one side and SMITHS SCREW JACK on the other. Single screw jack. 9" closed. Photos courtesy of NewMoody. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted:
Value:
|
|
|
Description The jack is a single screw. Closed height 10". On one side it is cast SMITHS SCREW JACK and on the other SUPER MAJOR 10. Applicable Vehicles: Not known Jack Handle Type: As shown in final photo. Year Dates Noted:
Value: Average price paid in 2014 = £2.00 - 1 sale Average price paid in 2021 = £17.00 - 1 sale
|
|
|
Smiths Super Major 10 Description This jack is completely different to the Super Major 10 immediately above. It is cast SMITHS SCREW JACK on one side and SUPER MAJOR 10 on the other. Single screw jack, 10 inches retracted and 17.5 inches extended. Applicable Vehicles: Not known Jack Handle Type: As shown in final photo. Year Dates Noted:
Value: Average price paid in 2014 = £4.85 - 1 sale Average price paid in 2018 = £5.00 - 1 sale
|
|
|
Description This single screw jack is 10 inches retracted and 17.5 inches extended. 3/4" square handle drive. It is cast SMITHS SCREW JACK on one side and 10 HEAVY MAJOR on the other. Courtesy of Ian Rendle. Applicable Vehicles: Not known Jack Handle Type: Possibly the same as the entry above. Year Dates Noted:
Value: Average price paid in 2021 = £20.00 - 1 sale
|
|
|
Smiths Description The jack is cast SMITHS on one side and nothing on the other. Double screw jack. 7" closed. The final photo shows the similarities with the Ern Lake 7" Balloon. Photos courtesy of NewMoody. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted:
Value:
|
|
|
Description The 2 screw jack is cast SMITH'S 5 1/4 INCH BALLOON. 6" closed height and 12 " extended. It has a remarkable likeness to both the Ern Lake and Harvey Frost Type 5 1/4 jacks. Final picture courtesy of NewMoody. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted:
Value: Average price paid in 2014 = £7.99 - 1 sale Average price paid in 2017 = £2.49 - 2 sales Average price paid in 2020 = £20.00 - 1 sale
|
|
|
Description This tower screw jack is very similar to Ern Lake Tower jacks and may have been made under licence from Ern Lake during WW2. It is cast SMITH'S No 7 TOWER JACK on one side and PATENTS PENDING RGD DSN 734056. Other details as shown in photos. Refer also to Ern Lake Tower Jacks. Applicable Vehicles: Not known but possibly WW2 military vehicles. Jack Handle Type: As shown (just) in first photo and Ern Lake handles. Year Dates Noted:
Value: Average price paid in 2018 = £85.00 - 1 sale
|
|
|
Description This jack is the same as above but with WW2 castings. Photos and information courtesy of NewMoody. Applicable Vehicles: Military vehicles. Jack Handle Type: As above Year Dates Noted: Patent and design numbers circa 1927 but probably made during WW2. Value: Average price paid in 2019 = £20.00 - 1 sale
|
|
|
Description Description as shown in the picture. It comes in 3 sizes: 7 inches high with a 4 1/2 inch single screw lift. 7 inches high with a 7 1/2 inch single screw lift. 10 inches high with a 7 1/2 inch single screw lift. Applicable Vehicles: Not known Jack Handle Type: Not known. Year Dates Noted:
Value:
|
|
|
Description Bottle jack as shown in the picture. cast 3 TONS. 14 Inches down. Extension not known. Applicable Vehicles: Not known Jack Handle Type: Not known. Year Dates Noted:
Value:
|
|
|
|
|
|
Description This lever action jack is cast 3/4 TON, No.1 3/4 TON BADGER LONDON. It is designed for light cars. 11 inches high with a 6 inch rise. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted:
Value:
|
|
|
Description This lever action jack is cast No.3 BADGER S.S.&S. LONDON. It is identical to the KK13 above except that has a 1 Ton capacity. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted:
Value:
|
|
|
Description This lever action jack is cast No.4 CAPACITY 1 TON BADGER. It is identical to the KK13 above except that has a 1 Ton capacity. It is for cars with a low height axle. It is 8 3/4 inches high with a 4 3/4 inch rise. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted:
Value:
|
|
|
Description This lever action jack is cast 1 TON No.6 1 TON BADGER LONDON. It has an adjustable foot and is for cars with a high height axle. It is 11 inches high. The adjustable foot can be regulated from 4 3/4 inches to 10 3/4 inches. The lever extension gives it an additional undisclosed extension. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted:
Value:
|
|
|
Description This lever action jack is cast 1 TON No.7 1 TON BADGER S.S.&S. LONDON. It is 11 inches high. The lever extension gives it a 6 inch extension. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted:
Value:
|
|
|
Description This lever action jack is cast BADGER TRUCK JACK on the main body and 3 TON on the handle shaft. It is 11 1/2 inches high. The lever extension gives it a 5 1/2 inch extension. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted:
Value:
|
|
|
Smiths Perfect Screw Jack KK20 Description This Ratchet screw jack is cast on the main body S. SMITH & SONS (MA) LTD and on the integrated handle PERFECT SCREW JACK. It has a 1 ton lifting capacity. 8 inches high with a 5 inch lift. Applicable Vehicles: Not known Jack Handle Type: Integrated Year Dates Noted:
Value:
|
|
|
Description This Lever jack is cast SMITH'S TRIUMPH FOOT LIFT. No other details known except as shown in the photo. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted:
Value:
|
|
|
Description This tyre saver & lifting jack is cast SS&S. Fits any wheel up to 42 inches. No other details known. Applicable Vehicles: Not known Jack Handle Type: Integrated Year Dates Noted:
Value:
|
|
|
Description Cast No.100 3TON. Other details as shown in the photo. 14 inches down. Extension not known. Applicable Vehicles: Not known Jack Handle Type: Not known. Year Dates Noted:
Value:
|
|
|
Description The jack is cast SMITHS ST FORTLAND ST LONDON at the top with SMITHS SINGLE ACTING JACK TYPE underneath. It is 10" closed and 16" extended. Other details as shown in the photos. Applicable Vehicles: Not known Jack Handle Type: As shown in 5th picture. Year Dates Noted: Circa 1920s (final 2 pictures). Value: Average price paid in 2014 = £13.03 - 1 sale Average price paid in 2015 = £24.95 - 1 sale Average price paid in 2018 = £142.00 - 1 sale
|
|
|
Description The jack is cast SMITHS DOUBLE ACTING JACK TYPE then PATENT 5200 stamped underneath. Height is 7 inches closed and 12 inches extended. Other details as shown in the photos. Courtesy of Stuart Pearce. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted: Likely to be circa 1920s as entry above. Value:
|
|
|
Description The jack is cast SMITHS PERFECT JACK vertically down one side. It is 8" closed and 12" extended. Other details as shown in the photos. Applicable Vehicles: Not known Jack Handle Type: Probably similar to entry above. Year Dates Noted: Probably 1920s as above. Value: Average price paid in 2018 = £20.00 - 1 sale Average price paid in 2019 = £15.00 - 1 sale
|
|
|
|
|
|
Description This hydraulic jack is 19.5" high retracted, extending to 30.5". The alloy body is cast on one side SMITHS JACKING SYSTEMS LTD CRICKLEWOOD LONDON and on the other USE ONLY JACKALL FLUID. The pressure release tap is stamped RELEASE, accompanied by an arrow. The lifting arm is fixed and is 1" diameter solid bar, 2.5" in length. Unusually for Smiths pole jacks this jack has no maker's name casting on the circular foot. I have seen other versions of this jack. They have a hydraulic fluid filler plug below the 'use only Jackall fluid'. This one is blanked off. The only obvious way to top up seems to be to invert the jack and unscrew the container. This type of jack was also provided to DWS (Donald W Sessons). My photos except the last. Applicable Vehicles: Rover 14 1945 tp 1948 Rover 16 1945 to 1948 This style of jack was also used by Riley (see next entry but one), Alvis, Rover saloons and Lanchesters. There could be others. The lifting lug varies with types. Jack Handle Type: Possibly as shown in the final picture, but see also next entry but one. Year Dates Noted: Circa 1945 to 1948. Value: Average price paid in 2014 = £29.00 - 1 sale Average price paid in 2019 = £33.31 - 3 sales Average price paid in 2020 = £10.50 - 1 sale Average price paid in 2021 = £30.00 - 1 sale Average price paid in 2022 = £20.00 - 1 sale Average price paid in 2023 = £38.95 - 1 sale
|
|
|
Description This hydraulic jack is similar to the jack immediately above. It is taller, being 23.5" high retracted, extending to 38.5". The alloy body is cast on one side SMITHS JACKING SYSTEMS LTD CRICKLEWOOD LONDON and on the other USE ONLY JACKALL FLUID. The pressure release tap is stamped RELEASE, accompanied by an arrow. The lifting arm is adjustable as shown in the final photo. However, somewhat unusually, the footpad is cast DWS JACKING SYSTEMS PAT APP FOR. Unlike the jack above this one has the fluid top up plug. This type of jack was also provided to DWS (Donald W Sessons). This could account for the apparent mix up in the DWS casting on the foot. My photos. Applicable Vehicles: This style of jack was used by Riley (see next entry), Alvis, Rover saloons and Lanchesters. There could be others. The lifting bracket varies with types. Information required about which car used this specific version. Jack Handle Type: Possibly as shown in the next entry. Year Dates Noted:
Value:
|
|
|
Description Details as shown in the photos. Applicable Vehicles: Riley 12-4 Monaco Saloon 1936. Believed to have been used in other pre war Riley, Alvis and Rover saloons. More information required please. Jack Handle Type: As shown in final picture. Year Dates Noted: Circa 1936 Value:
|
|
|
Description: The Smiths MA is a single hydraulic lift with a manual screw extension. The castellated screw nut is cast SMITHS-MA CRICKLEWOOD ENG. It is 9" closed and 20" fully extended. The hydraulic lift is 6" and the screw extension is 5". Applicable Vehicles: Not known. Jack Handle Type: As shown. Year Dates Noted:
Value: Average price paid in 2016 = £4.99 - 1 sale
|
|
|
|
|
|
Description: These integral Stevenson jacks were supplied as an optional extra for the 1932 Triumph Super 9. Two jacks were fitted. They are hydraulically operated by the handles shown in the photos. The final photo shows the jacks in the parts list (90 degrees out to their attachment position). The photos come from various sources so I am attributing them to the Pre 40 Triumph MC Club of which Denis Redrupp is the South East Area rep. Applicable Vehicles: Optional extra for the 1932 Triumph Super 9. Jack Handle Type: As shown in the photos. One of the owners is requiring a handle assembly. These are difficult to come by. If any reader knows of one that is available please contact me in the first instance and I will put you in touch. Year Dates Noted: 1932 Value:
|
|
|
Smiths Jackall Integrated Jacking System Description I only have the one photo of a pair of the rams; 4 of the pump/valve; 3 of the reservoir and the handle. Information about the complete system and specific cars which used it are most welcome. Applicable Vehicles: Rolls Royce Phantom III. Whole of production 1936 to 1939. Rolls Royce Wraith. Whole of production 1938 to 1939. MG YA, YB and YT. Lagonda LG6, LG45, V12 and 3-Litre. Wolseley 10 (optional), 12/48, 14/56 (optional), 14/60 and 18/85. Austin 16, 18, 20 and 28. Various other pre and post war cars. Information most welcome. Jack Handle Type: Detachable hydraulic pump handle. Year Dates Noted:
Value:
Average price paid in 2017 = £38.77 - 1 sale (reservoir) Average price paid in 2018 = £19.00 - 1 sale (pump switch) Average price paid in 2019 = £114.28 - 2 sales (jacks, pipes & canister) Average price paid in 2019 = £133.77 - 1 sale (pump/selector) Average price paid in 2019 = £57.89 - 1 sale (handle) Average price paid in 2020 = £7.00 - 1 sale - 2 jacks, selector and canister Average price paid in 2021 = £85.00 - 1 Sale - 4 jacks, selector and canister Average price paid in 2021 = £156.00 - 1 Sale - Complete System Average price paid in 2022 = £50.00 - 1 sale Average price paid in 2022 = £15.50 - 2 sales - 2 jacks Average price paid in 2023 = £25.00 - 1 sale - Pump/selector £102.00 paid on UK Ebay 25 February 2024 - Entire system
|
|
|
|
|
|
Description: A beautifully restored Smiths Garage Jack. It meaures 21" long; 11" high at the rear and a lift of 6.5". The plaque on the side reads SMITHS GARAGE JACK CRICKLEWOOD LONDON N.W.2 Type (blank) PAT Nos. 258739 259523. The plate on the top is cast TURN BOTTOM UP AND OIL THOROUGHLY KEEP CONTROL OF LEVER WHEN LOWERING. Many thanks to Chris Du Feu for the photos of his restoration. Applicable Vehicles: Garage jack Jack Handle Type: Integrated Year Dates Noted: Possibly circa 1931. Value: Average price paid in 2018 = £0.99 - 1 sale Average price paid in 2023 = £0.99 - 1 sale
|
      |
Description: Smiths garage jack, similar to above but possibly earlier. Brass plaque reads SMITHS GARAGE JACK CRICKLEWOOD LONDON N.W.2 Type K476a Pat Nos. 258739 259523. The jack is 45cm long This particular example has been in the possession of the Tilley & Son Garage, probably since new. The Company started trading in 1890 and is still going today with motorcycles. All photo and information courtesy of Tilleys Ltd Applicable Vehicles: Garage jack Jack Handle Type: Integrated Year Dates Noted:
Value: Average price paid in 2021 = £28.00 - 1 sale
|
